High Intensity Magnetic Separator

HIMS is a highly efficient equipment that uses the combined forced of magnetism, a pulsating slurry and gravity to beneficiate many weakly magnetic materials such as, hematite, martite, limonite, vanadium-bearing titan magnetite, manganese and limonite. It can also be used as a critical component in the purification of such nonferrous materials such as kaolin, quartz, feldspar, nepheline and ceramic.

High Intensity Magnetic Separator Technical Specifications:

Model	Max Feeding Size (mm)	Feeding Concentration (%)	Slurry Passing Through Capacity (m3/h)	Capacity of Ore (m3/h)	Power (kW)	Weight (t)
ZGT-500	1.0	10-40	0.5-1.0	0.05-0.25	13.5	1.5
ZGT-750	1.0	10-40	0.1-2.0	0.1-0.5	22	3
ZGT-1000	1.3	10-40	12.5-20	4-7	28.6	6
ZGT-1250	1.3	10-40	20-50	10-18	35	14
ZGT-1500	1.3	10-40	50-100	20-30	44	20
ZGT-1750	1.3	10-40	75-150	30-50	62	35
ZGT-2000	1.3	10-40	100-200	50-80	74	50
ZGT-2500	1.3	10-40	200-400	100-150	94	105
Note: The magnetic strength should be determined in accordance with the nature of the ore. ZGT Series High Gradient Magnetic Separators can be customer-made.
