Jaw Crusher

This jaw crusher is a perfect combination of modern science technology and the production practice, which can better satisfy the automatic production demands of vast customers. It can reach the crushing ratio of 4-6, and the shape of final product is even. It is widely applied to crush high hardness rocks, such as ore, slag, construction materials, marble, etc. The pressure resistance strength is under 200Mpa, which is suitable for primary crushing. It is proven to be reliable in mining, metallurgical industry, construction, road and railway building, conversancy, chemistry, etc.

Jaw Crusher Features:

Excellent bite in the cavity

The steep nip angle, the angle between the movable and fixed jaw dies, ensures good bite and good material flow down in the cavity.

High production and reduction

The stroke is amplified from the top to the bottom, which means that the stroke is always longest in the bottom of the cavity. This boosts the capacity as well as the reduction ratio, resulting in high production and better end-product gradation.

Easy to maintain

Areas where any wear is anticipated are engineered to be easy to replace or protected by sacrificial wear items. This ensures that maintenance of jaw crushers is easy and cost efficient over the long lifetime of the crusher.

Jaw Crusher Operating Principle:

Through the motor's wheels, the eccentric shaft is driven by the triangle belt to make the movable jaw rotate in a regulated track. Movable jaw plate periodically comes to fixed jaw plate, and away from fixed jaw plate accompany with the movement of movable jaw part. Therefore, the materials in the crushing cavity composed of fixed jaw plate, movable jaw plate and side liners can be crushed and discharged through the discharging opening.

Jaw Crusher Technical Specifications:
