Spiral Chute

Spiral Chute is a type of gravity separation equipment, which is applicable to separate metallic minerals whose granularity is between 4-0.02, such as iron as well as other nonferrous metals, rare metals and nonmetallic minerals with adequate gravity difference.

Spiral Chute Advantages:

Reasonable structure and small occupation area;
High recovery, high efficiency, and precise separation;
Light in weight, rust and corrosion resistant;
Simple installation and Minimal maintenance requirements;
Low operating cost and long operating life;
Reliable running with minimal operator attention;
Strong adaptability to fluctuation of feeding amount, density, size and grade

Spiral Chute Technical specifications:

ltems	Type	F	H	L	M	ML
Diameter	mm	680	1230	1230	1230	1230
Pitch Space	mm	380	590	710	590	590&710
Start Qty	--	Single/Twin/Triple	Single/Twin/Triple	Single/Twin/Triple	Single/Twin/Triple	Single/Twin/Triple
Turns/Start	-	5-12	3-12	3-12	3-12	3-12
Materials	-	Nylon/Polyurethane/Polyurea (Service life: from 5 years to 30 years)
Particle Size	mm	0.03-2	0.03-0.3	0.03-0.3	0.03-0.3	0.03-0.3
Slurry Density	%	10-55	10-55	10-55	10-55	10-55
Capacity	m3/start	2-3	5-15	5-25	5-15	5-15
Apply stage	-	Rougher Scavenger	Rougher Cleaner Scavenger	Rougher Cleaner Scavenger	Rougher Scavenger	Rougher Scavenger
Wash water	-	Available and Optional
HMC Splitters	-	Available and Optional (each turn or each two turns)
Applications	-	Gold /Tin/Chrome/Zircon/Rutile/lmenite/Hematite/Garnet/Barite
