Cone Crushers is widely used in mines, cement plants and sandstone industries for medium crushing of various mine rocks, such as iron ore, copper ore, non-ferrous metal ore, granite, sandstone, etc. Working principle is as follows: The cone body swings under the force of the eccentric shaft sleeve, so that the concave is sometimes close to and sometimes away from the mantle, so that the material is in an annular crushing cavity composed of concave and mantle impacted, crushed and bent to required particle size and discharged.
Cone Crusher Features:
Upgraded Structure, Higher Efficiency
Cone Crusher further optimizes the transmission parts and lubrication and sealing structures. which boasts strong holding capacity, bigger installed power, higher efficiency and lower noises.
Multiple Cavity Types Meet Various Particle Size
Cone Crusher has several kinds of cavities suitable for different size requirements. Users can adjust product size and shape by changing spare parts like concave, mantle.
PLC Integrated Control System Makes Operations Simpler
Cone Crusher adopts the advanced PLC electrical system, which can continuously detect the operation and give alarms, and display various operating parameters.
Cone Crusher Technical Specifications:
| Model | Cavities | Feed opening (mm) | Minimum discharging size (mm) | Capacities (t/h) | Nominal installed power (kw) | Maximum installed power (kw) | Overall dimension (mm) |
| HP300 | C1(Extra Coarse) | 230 | 25 | 220-440 | 220 | 250 | 2725×2110×2871 |
| C2(Coarse) | 210 | 19 | 190-380 | ||||
| M(Medium) | 150 | 16 | 175-320 | ||||
| F1(Fine) | 105 | 13 | 145-280 | ||||
| F2(Extra Fine) | 80 | 10 | 110-240 | ||||
| HP400 | C1(Extra Coarse) | 295 | 30 | 300-630 | 315 | 315 | 2775×2370×2295 |
| C2(Coarse) | 251 | 25 | 285-560 | ||||
| M(Medium) | 196 | 20 | 250-490 | ||||
| F1(Fine) | 110 | 13 | 180-345 | ||||
| F2(Extra Fine) | 90 | 10 | 135-320 | ||||
| GP100 | S1(超粗)Extra Coarse | 240 | 22 | 85-170 | 90 | 90 | 1550×1575×2545 |
| S2Medium Coarse | 200 | 19 | 70-130 | ||||
| H1Fine | 135 | 10 | 45-115 | 1550×1575×1965 | |||
| H2Medium Fine | 65 | 8 | 35-80 | ||||
| H3Extra Fine | 35 | 4 | 27-60 | ||||
| GP160 | S1Extra Coarse | 360 | 25 | 120-345 | 132 | 160 | 1875×1920×3195 |
| S2Medium Coarse | 300 | 22 | 105-305 | ||||
| S3Coarse | 235 | 19 | 90-275 | ||||
| H1Fine | 185 | 13 | 66-210 | 1875×1920×2400 | |||
| H2Medium Fine | 90 | 10 | 65-165 | ||||
| H3Extra Fine | 50 | 6 | 48-105 | ||||
| GP250 | S1Extra Coarse | 450 | 35 | 255-605 | 220 | 250 | 2100×2320×4096 |
| S2Medium Coarse | 400 | 29 | 215-515 | ||||
| S3Coarse | 300 | 25 | 190-490 | ||||
| H1Fine | 215 | 16 | 110-395 | 2100×2320×2780 | |||
| H2Medium Fine | 110 | 13 | 115-340 | ||||
| H3Extra Fine | 70 | 8 | 90-255 | ||||
| GP315 | S1Extra Coarse | 560 | 41 | 335-1050 | 315 | 315 | 2380×2735×4630 |
| S2Medium Coarse | 500 | 38 | 305-895 | ||||
| H1Fine | 275 | 16 | 170-665 | 2380×2735×3265 | |||
| H2Medium Fine | 135 | 16 | 190-505 | ||||
| H3Extra Fine | 65 | 13 | 205-320 |
